Proceedings of the International Conference on Digital Manufacturing –
Volume 2
EQUIVALENT STRAIN-DISPLACEMENT BEHAVIOR OF DIFFERENT LATTICE
STRUCTURES
BCC Kelvin Gyroid Tri HC HX HC Octet FCC Diamond Fluorite
0.80
0.70
0.60
EQUIVALENT STRAIN (MM/MM) 0.40
0.50
0.30
0.20
0.10
0.00
0 4 8 12 16
DISPLACEMENT (MM)
Figure 18: Comparison of equivalent strain versus displacement for
beams featuring various infill geometries
STRESS/MASS RATIO-DISPLACEMENT BEHAVIOR OF
DIFFERENT LATTICE STRUCTURES
BCC FCC Kelvin Octet TRI HC Fluorite Diamond Gyroid
35000
30000
25000
STRESS/MASS (MPA/KG) 20000
15000
10000
5000
0
2MM 5MM 10MM 15MM 20MM
DISPLACEMENT
Figure 19: Stress-to-mass ratio versus displacement curves obtained
from three-point bending tests on various lattice structures.
The graphs, illustrated in Figure 18 and 19, show different
stress/mass ratios at different vertical displacements on the
rectangular beam with different lattices; some were strut-based
36
